Description:

The core equipment and process for feeding layer hen meal can be summarized as follows: raw material receiving → crushing → batching → mixing → conveying → feed tower storage → in-shed feeding → residual feed recycling. The key objectives throughout the process are to ensure uniform particle size, uniform mixing, seamless conveying, and zero feed waste.

1. Raw Material Receiving and Initial Cleaning

Raw materials are hoisted into the silo, iron is removed by a permanent magnet drum, and a vibrating screen/initial cleaning screen removes large impurities such as straw and stones to prevent damage to subsequent equipment.

2. Crushing System

Grains such as corn are crushed by a crusher, and a grading screen controls the particle size (layer hen meal is generally 1.2-2.0mm, slightly finer for chicks and slightly coarser for laying hens); fans and dust collectors ensure a clean workshop and reduce dust.

3. Batching System

Batching silos (set according to raw material type), electronic batching scales (loss-in/cumulative scales), batching auger.

4. Mixing System

Twin-shaft paddle mixer (high mixing uniformity, short mixing time, mainstream); horizontal ribbon mixer (suitable for small to medium scale).

5. Conveying and Storage

6. In-house Feeding System

7. Residual Material Recovery and Cleaning
